69 F-Body Camaro/Firebird 340 Series Stealth Fuel Tank.
Aeromotive Inc. is a true high performance aftermarket manufacturer specializing in fuel delivery and fuel delivery components. Utilizing aerospace tolerances and procedures, three generations of track experience, and a meticulous approach to engineering, Aeromotive Fuel Systems has become the absolute pinnacle of performance fuel delivery.
Information:
muscle car stealth fuel tank; features fuel pump and baffle built right into tank; 69 Camaro/Firebird (F-Body) Stealth Tank
Application Summary:
| Year |
Make/Model |
| 1969 |
Chevrolet Camaro |
| 1969 |
Pontiac Firebird |
| Attributes |
| ASIN |
B00AQX2OIM |
| Attached Sump |
No |
| Baffled |
Yes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Capacity |
18, 18 |
| Color |
Silver |
| Country of Origin (Primary) |
US |
| Emission Code |
Off Road |
| Filler Neck Attached |
Yes |
| Finish |
Powder Coated |
| Fuel Cap Included |
No |
| Fuel Pump Included |
Yes |
| Fuel System Compatibility |
Carburation & Fuel Injection |
| Fuel Type |
Gas |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8413910000 |
| Hazardous Material Code |
N |
| Height |
10, 10 |
| Integrated Controller |
No |
| Length |
41, 41 |
| Life Cycle Status Code |
Available to Order |
| Lock Ring Included |
Yes |
| Material |
Steel, Powder Coated Steel |
| Maximum Current Draw |
13A @ 40PSI |
| Maximum Flow Rating |
340LPH |
| Maximum Pressure |
105PSI |
| Motor Style |
Brushed |
| Mounting Hardware Included |
No |
| Mounting Straps Included |
No |
| NAFTA Preference Criterion Code |
B |
| Negative Ground |
Yes |
| O-Ring Included |
Yes |
| Outlet Outside Diameter |
ORB-06 |
| Outlet Type |
Female |
| Pressure Range |
3-65 |
| Pulse Width Modulation Compatible |
Yes |
| Pump Design |
Turbine Impeller |
| Return Fitting Size |
ORB-06 |
| SDR Required Flag |
N |
| Sender Ohm Range |
0-90 |
| Sending Unit Included |
Yes |
| Series |
Stealth |
| Terminal Gender |
Male |
| Terminal Quantity |
3 |
| Terminal Type |
Threaded Stud |
| Universal Or Specific Fit |
Specific |
| Voltage |
12-16V |
| Warranty Time |
12 |
| Width |
22, 22 |
| GTIN |
00684980004823 |
