Canton 15-284A Oil Pan Dart LS Next Rear Sump Road Race Pan
Our LS NEXT rear sump road race oil pan is designed to take the changes that Dart has made to the LS block and completely maximize their effectiveness. Our pan features billet end caps that offer a precise fit to the unique pan rail of the Dart LS NEXT block. Our Pro-style oil recovery pouch is designed to maximize the horsepower that Dart freed up in the bottom end. Our diamond shape trap door baffle along with our anti-slosh baffle allow for maximum oil control in high performance driving situations.
Our LS NEXT rear sump road race oil pan is designed to take the changes that Dart has made to the LS block and completely maximize their effectiveness. Our pan features billet end caps that offer a precise fit to the unique pan rail of the Dart LS NEXT block. Our Pro-style oil recovery pouch is designed to maximize the horsepower that Dart freed up in the bottom end. Our diamond shape trap door baffle along with our anti-slosh baffle allow for maximum oil control in high performance driving situations.
- Designed to fit most rear sump applications
- 6.5 qt System Capacity
- Pro Style Oil Recovery Pouch
- Machined Billet Front & Rear Seals
- Removable Windage Anti-Slosh Baffle
- Diamond Shape Road Race Trap Door Baffle System
- 20mm Bung for Low Oil Warning Sensor
- Magnetic Drain Plug
- Provision for pan mounted dipstick
Information:
N/AApplication Summary:
-| Attributes | |
| Baffled | Yes, Yes |
| Capacity | 6.5 Quarts, 6.5 Quarts |
| Country of Origin (Primary) | US |
| Crank Scraper Included | No, No |
| Dipstick Port | No, No |
| Drain Plug Included | Yes, Yes |
| Emission Code | Legal US |
| Engine | Dart LS Next, Dart LS Next |
| Engine Make/Size | Chevy Small Block LS Series |
| Feature 1 | Pro-Style Recovery Pouch, Pro-Style Recovery Pouch |
| Feature 2 | Machined Billet Front & Rear Seals, Machined Billet Front & Rear Seals |
| Feature 3 | Diamond Shape Baffle Assembly, Diamond Shape Baffle Assembly |
| Feature 4 | Removable Windage/Anti-Slosh Baffle, Removable Windage/Anti-Slosh Baffle |
| Feature 5 | Provision for Pan Mounted Dipstick, Provision for Pan Mounted Dipstick |
| Feature 6 | Magnetic Drain Plug, Magnetic Drain Plug |
| Finish | Raw Aluminum, Raw Aluminum |
| Gasket Or Seal Included | No, No |
| Hardware Included | No, No |
| Harmonized Tariff Code (Schedule B) | 8409911000 |
| Hazardous Material Code | N |
| Kicked Out | Yes, Yes |
| Life Cycle Status Code | Available to Order |
| Material | .100 Aluminum, .100 Aluminum |
| Maximum Depth | 8.5" |
| NAFTA Preference Criterion Code | B |
| Pickup Included | No, No |
| Recommended Accessory 1 | 15-285 - Dart LS NEXT rear sump pickup for 15-286A pan, 15-285 - Dart LS NEXT rear sump pickup for 15-286A pan |
| Recommended Accessory 2 | 21-870 - LS Flywheel Cover for T56 Bellhousing, 21-870 - LS Flywheel Cover for T56 Bellhousing |
| Recommended Accessory 3 | 22-304 - LS NEXT Oil Pan Stud Kit, 22-304 - LS NEXT Oil Pan Stud Kit |
| Recommended Accessory 4 | 22-405 - Plug for 20mm bung if low oil warning sender is not used, 22-405 - Plug for 20mm bung if low oil warning sender is Not used |
| Recommended Accessory 5 | 22-620 - Billet Aluminum remote spin-on filter mount 13/16"-16 Thread, 22-620 - Billet Aluminum remote spin-on filter mount 13/16"-16 Thread |
| SDR Required Flag | N |
| Usage | Competition |
| Warranty Time | 1 |
| Windage Tray Included | No, No |
| GTIN | 00887753712370 |
