Canton 25-164 CM Oil Filter 3.4" Billet Spin-On 3/4 Inch -16 Thread 2 5/8 O-ring
This 3.4" tall billet spin-on filter has 3/4" -16 threads and a standard size 2-5/8" o-ring. Like all CM filters it features a billet aluminum body built for strength and durability for a lifetime of use. Heat sink ribs add to filter's functionality and aggressive aesthetic. The filters bottom cap is easily removed with four bolts for filter element inspection and replacement. A CM 2-1/4" tall synthetic fiber filter element which flows 12 GPM of hot engine oil with no loss of pressure and filters down to 8 microns comes preinstalled.
This 3.4" tall billet spin-on filter has 3/4" -16 threads and a standard size 2-5/8" o-ring. Like all CM filters it features a billet aluminum body built for strength and durability for a lifetime of use. Heat sink ribs add to filter's functionality and aggressive aesthetic. The filters bottom cap is easily removed with four bolts for filter element inspection and replacement. A CM 2-1/4" tall synthetic fiber filter element which flows 12 GPM of hot engine oil with no loss of pressure and filters down to 8 microns comes preinstalled.
- 3.4 in Body
- Standard size 2-5/8" O-ring
- Flows 12 GPM of hot engine oil
- 8 Micron Synthetic Element pre-installed For High Flow Fine Filtration
Information:
N/AApplication Summary:
-| Attributes | |
| Country of Origin (Primary) | US |
| Emission Code | Legal US |
| Feature 1 | 3.4 in Body, 3.4 in Body |
| Feature 2 | Flows 12 GPM of hot engine oil, Flows 12 GPM of hot engine oil |
| Feature 3 | 8 Micron Sythetic Element pre-installed For High Flow Fine Filtration, 8 Micron Sythetic Element pre-installed For High Flow Fine Filtration |
| Feature 4 | 3/4-16 Female Nut, 3/4-16 Female Nut |
| Feature 5 | 2 5/8 in Diameter O-Ring Gasket, 2 5/8 in Diameter O-Ring Gasket |
| Feature 6 | Removable End Cap, Removable End Cap |
| Finish | Raw Aluminum, Raw Aluminum |
| Harmonized Tariff Code (Schedule B) | 8421230000 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Material | Billet Aluminum, Billet Aluminum |
| NAFTA Preference Criterion Code | B |
| Recommended Accessory 1 | 26-200 - 2-1/4" Tall 8 Micron Oil Element - Single, 26-200 - 2-1/4" Tall 8 Micron Oil Element - Single |
| Recommended Accessory 2 | 26-220 - 2-1/4" Tall 8 Micron Oil Element - 6-Pack, 26-220 - 2-1/4" Tall 8 Micron Oil Element - 6-Pack |
| SDR Required Flag | N |
| Warranty Time | 1 |
| GTIN | 00887753717085 |
