25-548 Billet Aluminum Spin-On 4-1/4" Tall Oil Filter 20mm Standard O-Ring
This 4-1/4" tall billet spin-on filter has 20MM threads and a standard size 2-5/8" o-ring. Like all CM filters it features a billet aluminum body built for strength and durability for a lifetime of use. Heat sink ribs add to filter's functionality and aggressive aesthetic. The filters bottom cap is easily removed with five Allen head bolts for filter element inspection and replacement. A CM 2-5/8" tall synthetic fiber filter element which flows 15 GPM of hot engine oil with no loss of pressure and filters down to 8 microns comes preinstalled.
This 4-1/4" tall billet spin-on filter has 20MM threads and a standard size 2-5/8" o-ring. Like all CM filters it features a billet aluminum body built for strength and durability for a lifetime of use. Heat sink ribs add to filter's functionality and aggressive aesthetic. The filters bottom cap is easily removed with five Allen head bolts for filter element inspection and replacement. A CM 2-5/8" tall synthetic fiber filter element which flows 15 GPM of hot engine oil with no loss of pressure and filters down to 8 microns comes preinstalled.
- 4-1/4" tall billet spin-on filter has 20MM threads and a standard size 2-5/8" O-ring
- 2-5/8" tall synthetic fiber filter element flows 15 GPM of engine oil with no loss of pressure
- Features a billet aluminum body for strength and durability
- Heat sink ribs add to filters functionality and aggressive aesthetic
- Bottom cap is easily removed with four bolts for filter element inspection and replacement
- Made in the USA
Information:
-Application Summary:
-| Attributes | |
| Country of Origin (Primary) | US |
| Emission Code | Legal US |
| Feature #1 | 4-1/4" tall billet spin-on filter has 20MM threads and a standard size O-ring |
| Feature #2 | 2-5/8" tall synthetic fiber filter element flows 15 GPM of engine oil with no loss of pressure |
| Feature #3 | Features a billet aluminum body for strength and durability; Heat sink ribs add to filters functionality and aggressive aesthetic |
| Feature #4 | Bottom cap is easily removed with five bolts for filter element inspection and replacement |
| Feature #5 | Made in the USA |
| Feature 1 | 4.25 in Body |
| Feature 2 | Flows 15 GPM of hot engine oil |
| Feature 3 | 8 Micron Sythetic Element pre-installed For High Flow Fine Filtration |
| Feature 4 | 20mm Female Thread |
| Feature 5 | 2-5/8 in Diameter O-Ring Gasket |
| Feature 6 | Removable End Cap |
| Finish | Black Anodized |
| Harmonized Tariff Code (Schedule B) | 8421230000 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Material | Billet Aluminum |
| NAFTA Preference Criterion Code | B |
| Recommended Accessory #1 | 25-500 - Oil Bypass Cap for CM Spin-on Oil Filters |
| Recommended Accessory #2 | 26-000 - 2-5/8 Tall 8 Micron Oil Element - Single |
| Recommended Accessory #3 | 26-020 - 2-5/8 Tall 8 Micron Oil Element - 6-Pack |
| Recommended Accessory #4 | 26-040 - 2-5/8 Tall 8 Micron Oil Element - 24-Pack |
| Recommended Accessory 1 | 26-000 - 2-5/8 Tall 8 Micron Oil Element - Single |
| Recommended Accessory 2 | 26-020 - 2-5/8 Tall 8 Micron Oil Element - 6-Pack |
| Recommended Accessory 3 | 26-040 - 2-5/8 Tall 8 Micron Oil Element - 24-Pack |
| SDR Required Flag | N |
| Thread Size | 20mm |
| Warranty Time | 1 |
| GTIN | 00887753830821 |
