The Edelbrock Supercharger System part #15790 is for the 2007-13 Gen IV Silverado/Sierra 1500 6.2L. No Programmer is included which requires custom tuning done by the customer.
The Edelbrock supercharger Stage 1 Street system part #15790 for 2007-13 Silverado and Sierra 1500 increases the performance of your 6.2L Gen IV engine to 407 horsepower and 434 ft-lbs of torque at the crank when used with Edelbrock tune (kit supplied without a programmer). The core of this system is the Eaton Gen VI 2300 TVS rotating assembly with a four-lobe design with 160 degrees of twist for maximum flow, minimum temperature rise and quiet operation for excellent drivability. We also designed our superchargers with an integrated bypass valve to help eliminate parasitic loss under light throttle, improving mileage potential. Our unique and efficient inlet configuration results in a shorter, less restrictive intake path for improved airflow, without the need for a jack-shaft. Keeping the air cool is a high-capacity air-to-water intercooler and low-temp heat exchanger. HANDHELD PROGRAMMER NOT INCLUDED. Supercharger systems sold without tuners are only emissions legal when used with the correct Edelbrock program.
Application Summary:
| Year |
Make/Model |
| 2009-2013 |
Chevrolet Silverado 1500 |
| 2007-2013 |
GMC Sierra 1500 |
| Attributes |
| 9040 |
D-215-110 |
| Air Filter Included |
Yes |
| ASIN |
B007V94N2E |
| Calibration |
No |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| CARB Executive Order Number |
D-215-110, D-215-110 |
| Center Housing Cooling Type |
Intercooler |
| Country of Origin (Primary) |
US |
| Emission Code |
Legal US |
| Finish |
Black Powder Coated |
| Gasket Or Seal Included |
Yes, Yes, Yes |
| Harmonic Balancer Diameter |
7.5, 7.5, 7.5 |
| Harmonized Tariff Code (Schedule B) |
8708998175 |
| Hazardous Material Code |
N |
| Hose Included |
Yes, Yes, Yes |
| Housing Material |
Cast Aluminum, Cast Aluminum, Cast Aluminum |
| Internal Step Up |
Yes |
| Life Cycle Status Code |
Available to Order |
| Mounting Bracket Included |
Yes, Yes, Yes |
| Mounting Hardware Included |
Yes, Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Oil Capacity |
150, 150, 150 |
| Outside Pulley Diameter |
3.75 |
| Potential Risk Chemical |
Chrome |
| Pulley Belt Width |
6-Rib |
| Quantity |
Kit, Kit, Kit |
| RGL |
WARNING: This product can expose you to Chromium, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Chromium, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Rotor Type |
Eaton TVS 2300, Eaton TVS 2300, Eaton TVS 2300 |
| SDR Required Flag |
N |
| SDS Sheet Number |
NA |
| System Type |
Stage 1 - Street System |
| Universal Or Specific Fit |
Specific, Specific, Specific |
| Vehicle Model |
Sierra 1500, Silverado 1500, Silverado 1500, Silverado 1500 |
| Warranty Time |
36 |
| GTIN |
00085347157907 |
