Edelbrock Super Victor 440 Max Wedge Intake Manifold with 4500 Series Carb for Chrysler 413-426-440 Big-Block V8
Edelbrock part #2893 Super Victor 440 Max Wedge intake manifold is designed for 413-440-500+ RB with Max Wedge heads and 4500 Series carburetors. This intake manifold is designed to fit 1962-64 Max Wedge heads or the Edelbrock Victor Max Wedge cylinder heads #77939 and #77949 for maximum performance. For competition and high-rpm Chrysler V8's, the Super Victor 440 has an all-new runner design that delivers maximum power from 3500 to 8000 rpm in drag race applications. The manifold port exits are CNC machined to 1.30" x 2.58". Edelbrock part #7798 valley cover is required when used with Edelbrock Victor Series cylinder heads.
Application Summary:
| Year |
Make/Model |
| Chrysler:Big-Block |
RB-Series:413 (6.8L)/426 (7.0L)/440 (7.2L) |
| Attributes |
| ASIN |
B003D286P8 |
| Basic Operating RPM Range |
3500-8000, 3500-8000 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Center Maximum Height |
6.400, 6.4, 6.400, 6.400 |
| CNC Ported |
Yes, Yes |
| Color |
Silver |
| Color/Finish |
Natural/Satin |
| Country of Origin (Primary) |
US |
| Cylinder Head Type |
Standard |
| EGR Port |
No, No |
| Emission |
Without EGR |
| Emission Code |
Off Road |
| Engine Make/Size |
Mopar 413-440 |
| Finish |
Satin, Uncoated |
| Flange Type |
4500, 4500 |
| Front Maximum Height |
6.400, 6.4, 6.400, 6.400 |
| Fuel Injectors Included |
No |
| Gasket Or Seal Included |
No, No, No, No |
| Grade Type |
Performance, Performance, Performance, Performance |
| Harmonized Tariff Code (Schedule B) |
8708998175 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum, Aluminum, Aluminum, Aluminum |
| NAFTA Preference Criterion Code |
B |
| Number of Carbs |
One |
| Position |
N/A |
| Potential Risk Chemical |
Lead |
| Rear Maximum Height |
6.400, 6.4, 6.400 |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| RPM Range |
3500-8000 |
| SDR Required Flag |
N |
| SDS Sheet Number |
NA |
| Series |
Victor, Victor, Victor |
| Single Or Dual Plane Type |
Single Plane, Single Plane, Single, Single Plane |
| Usage |
Racing |
| Vehicle Model |
Chrysler, Chrysler |
| Warranty Time |
12 |
| GTIN |
00085347028931 |
