Edelbrock Super Victor 8.2 Intake Manifold for Ford 289-347 Small-Block V8
Edelbrock part #2928 Super Victor 8.2 intake manifold is designed for high-rpm and competition 302-347 engines with aftermarket Windsor-style racing cylinder heads such as the Edelbrock Victor heads #77219 or Victor Jr. heads #77169. The Super Victor 8.2 is for engines with a standard 8.2" deck height. Excellent for large displacement drag racing engines, this single plane race manifold delivers big power gains from 4500 to 8500 rpm and includes nitrous and rear cooling water bosses. The square-bore carburetor pad stands .850" taller than the Edelbrock Victor Jr. #2921.
Application Summary:
| Year |
Make/Model |
| Ford:Small-Block |
Windsor:260 (4.3L)/289 (4.7L)/302 (5.0L) |
| Attributes |
| ASIN |
B00062ZUWU |
| Basic Operating RPM Range |
4500-9000 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Center Maximum Height |
6.350, 6.350, 6.35 |
| CNC Ported |
No |
| Country of Origin (Primary) |
US |
| Cylinder Head Type |
Standard |
| EGR Port |
No |
| Emission |
Without EGR |
| Emission Code |
Off Road |
| Engine Make/Size |
Ford 260-302 |
| Finish |
Satin, Satin, Satin |
| Flange Type |
4150 |
| Front Maximum Height |
6.350, 6.35 |
| Gasket Or Seal Included |
No, No, No |
| Grade Type |
Performance, Performance, Performance |
| Harmonized Tariff Code (Schedule B) |
8708998175 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum, Aluminum, Aluminum |
| NAFTA Preference Criterion Code |
B |
| Number of Carbs |
One |
| Position |
N/A |
| Potential Risk Chemical |
Lead |
| Rear Maximum Height |
6.350, 6.35 |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| RPM Range |
4500-9000 |
| SDR Required Flag |
N |
| SDS Sheet Number |
NA |
| Series |
Victor, Victor |
| Single Or Dual Plane Type |
Single Plane, Single Plane, Single |
| Usage |
Racing |
| Vehicle Model |
Ford, Ford |
| Warranty Time |
12 |
| GTIN |
00085347029280 |
