The Edelbrock #5087 E-210 Cylinder heads are designed for use with 1955-1986 Small-Block Chevy applications. They feature larger runners for increased airflow, revised exhaust ports and larger diameter springs for higher lift camshafts.
The Edelbrock #5087 E-210 Cylinder heads are designed for use with 1955-1986 Small-Block Chevy applications. The Edelbrock E-Series cylinder heads are a step up in affordable performance from our E-Street line. They feature larger runners for increased airflow, revised exhaust ports and larger diameter springs for higher lift camshafts, making them ideal for a spec series racer and larger displacement engines. The Edelbrock #5027 E-Series Cylinder heads also have as-cast ports and maintain the stock exhaust port location, making them compatible with OEM headers and hardware.
Application Summary:
| Year |
Make/Model |
| 1965-1971 |
Avanti II |
| 1973-1974 |
Avanti II |
| 1976-1985 |
Avanti II |
| 1987-1991 |
Avanti II |
| 1977-1981 |
Buick Century |
| 1991-1993 |
Buick Commercial Chassis |
| 1978 |
Buick LeSabre |
| 1982 |
Buick LeSabre |
| 1977-1987 |
Buick Regal |
| 1991-1993 |
Buick Roadmaster |
| 1977-1979 |
Buick Skylark |
| 1966-1974 |
Checker Aerobus |
| 1969-1970 |
Checker Deluxe |
| 1965-1982 |
Checker Marathon |
| 1969-1974 |
Checker Taxicab |
| 1959 |
Chevrolet 3B |
| 1959 |
Chevrolet 3C |
| 1959 |
Chevrolet 3D |
| 1959 |
Chevrolet 3E |
| 1959 |
Chevrolet 3F |
| 1959 |
Chevrolet 3G |
| 1958-1975 |
Chevrolet Bel Air |
| 1981 |
Chevrolet Bel Air |
| 1958-1972 |
Chevrolet Biscayne |
| 1969-1974 |
Chevrolet Blazer |
| 1958-1961 |
Chevrolet Brookwood |
| 1969-1972 |
Chevrolet Brookwood |
| 1975-1986 |
Chevrolet C10 |
| 1960-1974 |
Chevrolet C10 Pickup |
| 1967-1986 |
Chevrolet C10 Suburban |
| 1975-1986 |
Chevrolet C20 |
| 1960-1974 |
Chevrolet C20 Pickup |
| 1967-1986 |
Chevrolet C20 Suburban |
| 1975-1986 |
Chevrolet C30 |
| 1960-1974 |
Chevrolet C30 Pickup |
| 1960-1962 |
Chevrolet C40 |
| 1967-1986 |
Chevrolet Camaro |
| 1966-1986 |
Chevrolet Caprice |
| 1964-1973 |
Chevrolet Chevelle |
| 1963-1968 |
Chevrolet Chevy II |
| 1955-1982 |
Chevrolet Corvette |
| 1984-1986 |
Chevrolet Corvette |
| 1957-1958 |
Chevrolet Del Ray |
| 1959-1960 |
Chevrolet El Camino |
| 1964-1986 |
Chevrolet El Camino |
| 1969-1970 |
Chevrolet Estate |
| 1975-1986 |
Chevrolet G10 |
| 1968-1974 |
Chevrolet G10 Van |
| 1975-1986 |
Chevrolet G20 |
| 1967-1974 |
Chevrolet G20 Van |
| 1975-1986 |
Chevrolet G30 |
| 1974 |
Chevrolet G30 Van |
| 1958-1985 |
Chevrolet Impala |
| 1975-1986 |
Chevrolet K10 |
| 1960-1974 |
Chevrolet K10 Pickup |
| 1967-1986 |
Chevrolet K10 Suburban |
| 1975-1986 |
Chevrolet K20 |
| 1967 |
Chevrolet K20 Panel |
| 1960-1974 |
Chevrolet K20 Pickup |
| 1967-1986 |
Chevrolet K20 Suburban |
| 1977-1986 |
Chevrolet K30 |
| 1968-1974 |
Chevrolet K30 Pickup |
| 1975-1986 |
Chevrolet K5 Blazer |
| 1959-1961 |
Chevrolet Kingswood |
| 1969-1972 |
Chevrolet Kingswood |
| 1975 |
Chevrolet Malibu |
| 1978-1983 |
Chevrolet Malibu |
| 1970-1986 |
Chevrolet Monte Carlo |
| 1975-1979 |
Chevrolet Monza |
| 1958-1961 |
Chevrolet Nomad |
| 1969-1979 |
Chevrolet Nova |
| 1955-1957 |
Chevrolet One-Fifty Series |
| 1959-1961 |
Chevrolet Parkwood |
| Attributes |
| ASIN |
B004A7RNY0 |
| Assembled |
Yes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Camshaft Type |
Hydraulic Roller, Hydraulic Roller, Hydraulic Roller, Hydraulic Roller |
| CNC Ported |
No, No |
| Combustion Chamber Volume |
64, 64 |
| Construction Type |
Complete, Complete |
| Country of Origin (Primary) |
US |
| Cylinder Head Type |
Standard |
| Deck Height |
9.025 |
| Deck Thickness |
0.5625, 0.5625, 0.5625, 0.5625 |
| EGR Port |
No |
| Emission |
Non-Emissions |
| Emission Code |
Off Road |
| Engine Make/Size |
Chevy Small Block (262-400) |
| Exhaust Port Location |
Standard, Standard, Standard |
| Exhaust Runner Volume |
75 |
| Exhaust Valve Diameter |
1.60, 1.60, 1.6 |
| Family |
E-Series, E-Series, E-Series, E-Series |
| Finish |
Polished |
| Grade Type |
Performance, Performance, Performance, Performance |
| Guide Material |
Manganese Bronze, Manganese Bronze, Manganese Bronze, Manganese Bronze |
| Guide Plate Material |
Hardened Steel, Chromoly Steel |
| Guide Plates Included |
Yes, Yes |
| Harmonized Tariff Code (Schedule B) |
8708998175 |
| Hazardous Material Code |
N |
| Head Casting Number |
N/A, N/A, N/A, 5086P |
| Horsepower |
400-550, 400-550, 400-550, 400-550 |
| Intake Runner Volume |
210, 210, 210, 210 |
| Intake Valve Diameter |
2.08 |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum, Aluminum, Aluminum, Aluminum |
| Mounting Hardware Included |
No |
| NAFTA Preference Criterion Code |
B |
| Potential Risk Chemical |
Lead |
| Preparation |
Bolt On (Not Required) |
| Push Rod Diameter |
(Suggested) 0.5625, (Suggested) 0.5625, (Suggested) 0.5625, (Suggested) 0.5625 |
| Quantity |
Set of 2, Set of 2, Set of 2, Set of 2 |
| Retainer Included |
Yes, Yes, Yes, Yes |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Rocker Arm Stud Diameter |
0.375 |
| Rocker Stud Diameter |
0.375, 0.375 |
| Rotor Center Bore Inside Diameter |
Straight, Straight |
| SDR Required Flag |
N |
| SDS Sheet Number |
NA |
| Seat Angle |
Exhaust 45 deg/Intake 45, Exhaust 45 deg/Intake 45 |
| Seat Material |
Ductile Iron, Ductile Iron, Ductile Iron, Ductile Iron |
| Series |
E-Series, E-Series, E-Series, E-Series |
| Type |
Complete |
| Usage |
Competition |
| Valve Angle |
23, 23, 23, 23 |
| Valve Included |
Yes, Yes, Yes |
| Valve Lock Material |
Steel |
| Valve Seals Included |
Yes |
| Valve Spring Diameter |
1.55, 1.55 |
| Valve Spring Maximum Lift |
0.650, 0.650, 0.65 |
| Valve Springs Included |
Yes, Yes |
| Valve Stem Diameter |
0.3438 |
| Warranty Time |
12 |
| GTIN |
00085347050871 |
