| Air Conditioning |
Yes, Yes, Yes |
| Application |
Automotive |
| ASIN |
B000CO9D0W |
| Automatic Transmission - Column |
Yes, Yes, Yes |
| Automatic Transmission - Floor |
Yes, Yes, Yes |
| Bolts/Studs Included |
Yes, Yes, Yes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Catalytic Converter(s) Included |
NO, No, No |
| Coating/Finish |
Painted |
| Collector Attachment |
Stock, Stock |
| Collector Bolts Included |
Yes, Yes |
| Collector Diameter |
Stock, Stock |
| Collector Gasket Included |
No (Requires GM #15093974, or equivalent, exhaust seal), No (Requires GM #15093974, or equivalent, exhaust seal), No (Requires GM #15093974, or equivalent, exhaust seal) |
| Collector Size |
Stock, Stock, Stock |
| Collector Style |
Stock Collector, Stock Collector, Stock Collector |
| Collector Tube Size (in.) |
OEM |
| Contents |
Headers, gaskets, header & collector bolts/nuts. Collector donuts not included!, Headers, gaskets, header & collector bolts/nuts. Collector donuts not included!, One pair of headers, head flange gaskets, collector flange gaskets (when applicable), 3-bolt exhaust adapters, mounting hardware |
| Country of Origin (Primary) |
US |
| Crossover Pipe Included |
NO, No, No |
| Cylinder Head |
Stock Profile Heads, Stock Profile Heads, Stock Profile Heads |
| Cylinder Head Port Shape |
Oval, Oval, Oval |
| E.O. # |
Yes, Yes, Yes |
| Emission Code |
Legal US |
| Emissions Notes |
EO# D167-33 (click here for covered vehicles in document on ARB.CA.GOV website), EO# D167-33 (click here for covered vehicles in document on ARB.CA.GOV website) |
| Engine Make/Size |
Chevy 5.7L (Vortec) |
| Exhaust System Dia |
Factory hookup, Factory hookup |
| Finish |
Uncoated, Uncoated |
| Finish Type |
Uncoated Mild steel, Uncoated Mild steel, UNCOATED Mild Steel! Shipped with Temporary Paint. |
| Flange Style |
Standard, Standard, Standard |
| Flange Thickness |
0.3125", 0.3125 in., 0.3125 in. |
| Gasket # |
27520 |
| Gasket Or Seal Included |
Yes, Yes, Yes |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Head Flange Gasket |
27520 |
| Header Construction |
Standard-Duty, MILD STEEL- Standard-Duty |
| Header Fasteners Included |
Yes, Yes |
| Header Finish |
Uncoated, Uncoated, Uncoated |
| Header Material |
Mild Steel, Mild Steel, Mild Steel |
| Header Port Shape |
Oval Port, Oval Port, Oval Port |
| Header Style |
Short Tube, Short Tube |
| Installation Hardware Included |
Yes, Yes, Yes |
| Life Cycle Status Code |
Available to Order |
| Manual Transmission - Column |
No, No, No |
| Manual Transmission - Floor |
Yes, Yes, Yes |
| Material |
Mild Steel, Mild Steel |
| Motor Mounts (Included) |
NO, No |
| Motor Mounts Included |
NO, No, No |
| Mounting Hardware Included |
Yes, Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Notes |
96-00 Chev. 1/2, 3/4, 1 Ton Truck 2-4WD, 96-00 Chev. 1/2, 3/4, 1 Ton Truck 2-4WD, 96-00 Chev. 1/2, 3/4, 1 Ton Truck 2-4WD |
| Package Contents |
One pair of headers, head flange gaskets, collector flange gaskets (when applicable), 3-bolt exhaust adapters, mounting hardware, Headers, gaskets, header & collector bolts/nuts. Collector donuts not included! |
| Port Shape |
Oval, Oval, Oval |
| Power Steering |
Yes, Yes, Yes |
| Primary Tube Diameter (in) |
1.50", 1.50 in., 1.50 in. |
| Primary Tube Gauge |
16g, 16g, 16g |
| Quantity |
Sold as a pair., Sold as a pair., Sold as a pair. |
| Reducer Outlet Size |
Stock, Stock |
| Reducers Included |
NO, No, No |
| Replacement Gasket |
27520, 27520, 27520 |
| Replacement Head Flange Gasket |
27520, 27520 |
| SDR Required Flag |
N |
| Special Engine Notes |
VORTEC, VORTEC, VORTEC |
| Transmission Mount Included |
NO |
| Transmission Mount/Crossmember (Included) |
No, No |
| Transmission Mount/Crossmember Included |
No |
| Tube Design |
SHORT TUBE, SHORT TUBES, SHORT TUBES, Standard |
| Tube Diameter |
1-1/2 in., 1-1/2" |
| Tube Direction |
Down Swept |
| Tube Length |
SHORT Tubes, Short Tubes, Short Tubes |
| Tube Material Thickness |
16g, 16g, 16g |
| Tube Size |
1-1/2", 1-1/2 in., 1-1/2 in. |
| Tube Style |
Shorty, Shorty, Shorty |
| Tuned |
NO, No, No |
| Variations |
69656, 69656, 69656 |
| Weld-Up |
No, No, No |
| with A.I.R. |
No |
| with A.I.R. System |
No, No, No |
| with EGR |
No, Yes, Yes |
| Y-Pipe Included |
No, No, No |
| GTIN |
00732611696500 |
