Hedman Hedders has been manufacturing quality headers in the USA since 1954, and they've been manufacturing Ford truck headers decades. Each set uses mild steel, smooth flowing, CNC mandrel bent tubes, that are hand-welded to ensure each pair is identical to the next. Hedman's unique, gasketless ball and socket collector design allows your exhaust system to bolt up to these Big Block Ford 385 headers, even if it is not perfectly aligned with the header collectors.
These uncoated, LONG-TUBE headers fit 1974-79 Ford 1/2, 3/4 and 1 ton, 2WD Trucks with a 429-460 engine. These headers have been successfully tested and assigned E.O. number D167-27 by C.A.R.B., making these headers 50-state legal on the emissions-controlled 1975-1979 models without A.I.R. System. The long, smooth-flowing 1-3/4 in. tube design provides excellent exhaust flow to let your F-Series Ford truck's factory Big Block engine breathe easy, and produce loads of horsepower and torque. They fit manual and auto transmissions, but will not install on Camper Special or front swaybar equipped models.
These headers are uncoated, and ship from the factory with a temporary black paint that will burn off when submitted to normal operating temperatures. For protection against the element and lower underhood temperatures, these headers are also available with a silver or black ceramic-metallic finish.
Each set includes a pair of gaskets, header flange bolts and collector bolts. No collector gasket is needed.
Hedman Hedders is so confident in the quality of its headers that these headers are factory backed by a Limited Lifetime Warranty.
- Handcrafted, Mild Steel Construction.
- Long Tube Header Design Provides Excellent Top-End Horsepower and Torque.
- Ball & Socket Collector Design requires No Gasket, and Allows For More Exhaust System Misalignment than Old School, Gasket-Style Header Collectors
- Includes All The Necessary Mounting Hardware, Gaskets and Reducers (exhaust adapters)
- Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating!
- Proud To Say, Made In The USA, Since 1954!
Application Summary:
| Year | Make/Model |
|---|---|
| 1975-1979 | Ford F-150 |
| 1975-1979 | Ford F-250 |
| 1975-1979 | Ford F-350 |
| Attributes | |
| Air Conditioning | Yes, Yes, Yes |
| Application | Automotive |
| ASIN | B000COBJQI |
| Automatic Transmission - Column | Yes, Yes, Yes |
| Automatic Transmission - Floor | Yes, Yes, Yes |
| Bolts/Studs Included | Yes, Yes, Yes |
| California Proposition 65 | WARNING: Cancer - www.P65Warnings.ca.gov |
| Catalytic Converter(s) Included | No, No, No |
| Coating/Finish | Painted |
| Collector Attachment | 3", 3 in., 3 in. |
| Collector Bolts Included | Yes, Yes, Yes |
| Collector Diameter | 3 in., 3 in. |
| Collector Size | 3", 3 in., 3 in. |
| Collector Style | Ball and Socket Style (Gasketless), BALL and SOCKET Style (Gasketless), BALL and SOCKET Style (Gasketless) |
| Collector Tube Size (in.) | 3 |
| Contents | headers, gaskets (when applicable), 3-bolt exhaust adapters, hardware, headers, gaskets (when applicable), 3-bolt exhaust adapters, hardware, One pair of headers, head flange gaskets, collector flange gaskets (when applicable), 3-bolt exhaust adapters, mounting hardware |
| Country of Origin (Primary) | US |
| Crossover Pipe Included | NO, No, No |
| Cylinder Head | Stock Profile Heads, Stock Profile Heads, Stock Profile Heads |
| Cylinder Head Port Shape | Oval, Oval, Oval |
| Drivetrain | 2WD |
| E.O. # | Yes, Yes, Yes |
| Emission Code | Legal US |
| Emissions Notes | EO# D167-27 (click here for covered vehicles in document on ARB.CA.GOV website), EO# D167-27 (click here for covered vehicles in document on ARB.CA.GOV website) |
| Engine Make/Size | Ford 429-460 |
| Exhaust System Dia | 2-1/2", 2-1/2 in., 2-1/2 in. |
| Finish | Uncoated, Uncoated |
| Finish Type | Uncoated Mild steel, Uncoated Mild steel, UNCOATED Mild Steel! Shipped with Temporary Paint. |
| Flange Style | Standard, Standard, Standard |
| Flange Thickness | 0.375", 0.375 in., 0.375 in. |
| Footnotes | 6. Modification to stock exhaust required to retain catalytic converter., 6. Modification to stock exhaust required to retain catalytic converter. |
| Gasket # | 27770 |
| Gasket Or Seal Included | Yes, Yes, Yes |
| Harmonized Tariff Code (Schedule B) | 8708925000 |
| Hazardous Material Code | N |
| Head Flange Gasket | 27770 |
| Header Construction | Standard-Duty, MILD STEEL- Standard-Duty |
| Header Fasteners Included | Yes, Yes |
| Header Finish | Uncoated, Uncoated, Uncoated |
| Header Material | Mild Steel, Mild Steel, Mild Steel |
| Header Port Shape | Oval Port, Oval Port, Oval Port |
| Header Style | Long Tube, Long Tube |
| Installation Hardware Included | Yes, Yes, Yes |
| Life Cycle Status Code | Available to Order |
| Manual Transmission - Column | Yes, Yes, Yes |
| Manual Transmission - Floor | Yes, Yes, Yes |
| Material | Steel, Mild Steel, Mild Steel |
| Motor Mounts (Included) | NO, No |
| Motor Mounts Included | NO, No, No |
| Mounting Hardware Included | Yes, Yes, Yes |
| NAFTA Preference Criterion Code | B |
| Notes | 74-79 Ford 1/2, 3/4, 1 Ton Trucks; 2WD 429-460, 74-79 Ford 1/2, 3/4, 1 Ton Trucks; 2WD 429-460, 74-79 Ford 1/2, 3/4, 1 Ton Trucks; 2WD 429-460 |
| Package Contents | One pair of headers, head flange gaskets, collector flange gaskets (when applicable), 3-bolt exhaust adapters, mounting hardware, Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware, Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware |
| Port Shape | Oval, Oval, Oval |
| Power Steering | Yes, Yes, Yes |
| Primary Tube Diameter (in) | 1.75", 1.75 in., 1.75 in. |
| Primary Tube Gauge | 18g, 16g, 16g |
| Quantity | Sold as a pair., Sold as a pair., Sold as a pair. |
| Reducer Outlet Size | 2-1/2", 2-1/2 in., 2-1/2 in. |
| Reducers Included | Yes, Yes, Yes |
| Replacement Gasket | 27770, 27770, 27770 |
| Replacement Head Flange Gasket | 27770, 27770 |
| SDR Required Flag | N |
| Transmission Mount Included | NO |
| Transmission Mount/Crossmember (Included) | No, No |
| Transmission Mount/Crossmember Included | No |
| Tube Design | LONG TUBE, LONG TUBES, Standard |
| Tube Diameter | 1-3/4 in., 1-3/4" |
| Tube Direction | Down Swept |
| Tube Length | LONG Tubes, Long Tubes, Long Tubes |
| Tube Material Thickness | 18g, 16g, 16g |
| Tube Size | 1.75, 1-3/4", 1-3/4 in., 1-3/4 in. |
| Tube Style | Long Tube, Long Tubes, Long Tubes |
| Tuned | NO, No, No |
| Variations | 89146, 89840, 89146, 89840, 89146, 89840 |
| Weld-Up | No, No, No |
| with A.I.R. | No |
| with A.I.R. System | No, No, No |
| with EGR | No, No, No |
| Y-Pipe Included | No, No, No |
| GTIN | 00732611891400 |
